It was acquired as surplus from a working lab. It has been tested and holds a strong vacuum. Pumping speed 50 Hz7.3 m.
Pumping speed 60 Hz4.8 cfm. Ultimate vacuum: 70 mbar / 52 torr. Lower ambient temperature (operation): 10 °C. Upper ambient temperature (operation): 40 °C. Lower ambient temperature (storage): -10 °C.Upper ambient temperature (storage): 60 °C. Inlet connection: Hose nozzle DN 8-10 mm. Outlet connection: 2 x G1/4. Rated motor power: 0.25 kW. Rated motor speed at 50/60 Hz: 1500/1800 min.
Protection class IEC 60529IP 40. Dimension L in mm: 328 mm. Dimension B in mm: 239 mm. Dimension H in mm: 198 mm. At Fairfax Projects, we understand you have many choices and many considerations for choosing us. We strive to provide you with the best products and services at the best prices. Please reach out for any reason.
